技术参数 |
|
|
重量 |
240 g |
|
尺寸 |
95 x 75 x 30.5 mm |
|
操作温度 |
-30 ~ +50 °C |
|
防护等级 |
IP65 |
|
测量比例 |
Dependent on Cloud licence; Basic: 15 min … 24 h / Advanced: 1 min … 24 h |
|
Door contact |
是 |
|
Communication rate |
Dependent on Cloud licence; Basic: 15 min … 24 h / Advanced: 1 min … 24 h |
|
无线局域网络连接 |
Signal transmission: wireless, frequency band: 2.4 GHz, supported wireless LAN standards: IEEE 802.11 b/g/n and IEEE 802.1X; Possible encryption methods: without encryption, WEP, WPA, WPA2, WPA2 Enterprise - The data loggers communicate via the standard protocol MQTT and are SNTP time synchronization-capable. |
|
标准 |
DIN EN 12830 |
|
连接外置 |
外置温度探头 |
|
电源 |
4节5号电池；电源可选；温度低于-10 °C时请使用劲量电池0515 0572 |
|
存储量 |
10,000 测量值(管道) |
|
电池寿命 |
12 months (typical value, depending on the wireless LAN infrastructure) at +25 °C, 15-minute measuring cycle and standard communication cycle at -30 °C, 15-minute measuring cycle and standard communication cycle with Energizer batteries 0515 0572 |
|
存放温度 |
-40 ~ +70 °C （不含电池） |
|
NTC |
|
|
测量范围 |
-50 ~ +150 °C |
|
测量精度 |
±0.3 °C |
|
分辨率 |
0.1 °C |
