探头插孔
|
1
|
|
传感器类型
|
Thermocouple K, J (Selectable by the internal dip-switch)
|
|
测量范围
|
K: -160~+1372°C (-256~+2502°F)
J: -170~+1000°C (-274~+1832°F) |
|
分辨率
|
199.9°C(391.8°F) and below : 0.1°C(0.2°F)
200°C(392°F) and above : 1°C(1°F) |
|
精度
(at 25°C(77°F) ± 5°C(41°F)) |
0~199.9°C(32~391.8°F) : +0.1% of reading + 0.7°C(1.3°F)
-0.1°C(31.8°F) or less : +0.2% of reading + 1°C(1.8°F) 200°C(392°F) above : +0.2 of readubg + 1°C(1.8°F) |
|
采样率
|
Approx. 1.2 sec./reading
|
|
性能
|
°C/°F, Auto-Power off, Data Hold,
Data Record(Max/Min/Memory), Relative Measurement |
|
Input Connection
|
Waterproofing Connector
|
|
电源
|
006P(9V) Battery
|
|
电池寿命
|
Approx. 450 Hours
|
|
操作环境 |
0~90%RH at 0~35°C (32~95°F)
|
|
尺寸/质量
|
165(H) x 68(W) x 35(D)mm, 220g
|
|
防水等级
|
IP65(IEC60529)
|
|
附件
|
Instruction Manual, One battery 006P(9V)
|
